Application example(s):
Setup is in the metric system and then changed over to the inch system.
Special cases:
10260 CONVERT_SCALING_SYSTEM EXP -, G2, B3, K3, N3
- Enable basic system conversion BOOLEAN PowerOn
LINK
808d-me42 - TRUE 0 - 0/0 S
808d-me62 - TRUE 0 - 0/0 S
808d-te42 - TRUE 0 - 0/0 S
808d-te62 - TRUE 0 - 0/0 S
808d-mte40 - TRUE 0 - 1/1 M
808d-mte60 - TRUE 0 - 1/1 M
Description: Determines the handling of MD10240 $MN_SCALING_SYSTEM_IS_METRIC.
0: Inch/metric behavior conforms to SW1-SW4
1: Inch/metric behavior from SW5
Inch/metric functionality of SW5:
1. Switch over the systems of units with HMI softkey
2. New G codes G700/G710
3. Data backup with system of unit recognition INCH/METRIC
4. Automatic data conversion on change of system of units
● All zero point offsets
● Compensation data (EEC, QEC)
● Tool offsets
● etc.
The change from MD10260 $MN_CONVERT_SCALING_SYSTEM leads to alarm 4070!
This alarm is designed to indicate that data which remain active after a POWERON are
not subjected to automatic conversion from SW1-SW4 and SW5 formats.
10280 PROG_FUNCTION_MASK EXP, N01 K1
- Bit screen form to parameterize various part program commands DWORD PowerOn
-
808d-me42 - 0x10 0 0x1F 0/0 S
808d-me62 - 0x10 0 0x1F 0/0 S
808d-te42 - 0x10 0 0x1F 0/0 S
808d-te62 - 0x10 0 0x1F 0/0 S
808d-mte40 - 0x0 0 0x1F 7/2 M
808d-mte60 - 0x0 0 0x1F 7/2 M
Description: Bit screen form for parameterizing various part program commands
Bit Hexadec. Meaning with bit set
Value
0: 0x1 Comparison commands ">" and "<" are processed as with SINUMERIK 840D:
Part program data of the type REAL are mapped internally in the IEEE 64 bit
format. This mode maps decimal numbers inaccurately if this format's 52-bit wide
mantissa is inadequate to map the number in binary notation. To solve this problem,
all
comparison
commands
( ==, <>, >=, <=, > and < ) are checked for relative equality
of 1E-12.
This procedure is deactivated for greater than (>) and less than ( < )
comparisons by setting bit 0. (Compatibility setting for SINUMERIK 840D)
1: 0x2 Programming the channel names from machine data MD20000 $MC_CHAN_NAME
Machine data
3.2 General machine data
Parameter Manual
38 List Manual, 01/2017
