Signal irrelevant for ... if JOG mode is not active.
Note for the reader Function Manual Basic Functions K1
DB3000
DBX1.6
Single block type B
Edge evaluation: No Signal(s) updated:
Signal state 1 or edge
change 0 → 1
Bit set and DB3000 DBX1.7 not set: Response across mode groups
● Channel is stopped.
● Channel receives a start command.
●
Channel KS stops at the end of the block.
(If DB3000 DBX1.6 and DB3000 DBX1.7 are set simultaneously, it is impos‐
sible to determine which single block type is required. The control then as‐
sumes: No single block across mode groups.)
Signal state 0 or edge
change 1 → 0
If bit DB3000 DBX1.6 is not set and bit DB3000 DBX1.7 is set, then it is single
block type A.
(If DB3000 DBX1.6 and DB3000 DBX1.7 are not set, it is impossible to de‐
termine which single block type is required. The control then assumes: No
single block across mode groups).
corresponding to ... Single block type A
Note for the reader
DB3000
DBX1.7
Single block type A
Edge evaluation: No Signal(s) updated:
Signal state 1 or edge
change 0 → 1
DB3000 DBX1.7 set and DB3000 DBX1.6 not set: Response across modes
● Channel is stopped.
● Channel receives a start command.
●
Channel KS stops at the end of the block.
(If DB3000 DBX1.6 and DB3000 DBX1.7 are set simultaneously, it is impos‐
sible to determine which single block type is required. The control then as‐
sumes: No single block access across modes).
Signal state 0 or edge
change 1 → 0
If DB3000 DBX1.7 is not set and DB3000 DBX1.6 is set, then it is single block
type B.
(If DB3000 DBX1.6 and DB3000 DBX1.7 are not set, it is impossible to de‐
termine which single block type is required. The control then assumes: No
single block access across modes).
corresponding to ... Single block type B
Note for the reader
DB3000
DBX2.0 to .6
Machine function 1 INC, 10 INC, 100 INC, 1000 INC, 10000 INC, var. INC,
continuous
Signal(s) to modes (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.6 Mode signals
