DB3200
DBX1000.3
DBX1004.3
DBX1008.3
Feedrate stop for axes in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The signal is only active in the JOG mode (axes are traversed in the Work).
● The
signal triggers
a feedrate stop for the axis. For a traversing axis, this
signal brings it to a standstill with a controlled braking (ramp stop). No
alarm is output.
● The position control is kept, i.e. the following error is eliminated.
● If a travel request is issued for an axis with an active "feedrate stop", then
this is kept. This queued travel request is executed immediately after the
"feedrate stop" has been withdrawn.
Signal state 0 or edge
change 1 → 0
● The feedrate is enabled for the axis.
● If a travel
request ("travel command") is active when the "feedrate stop"
is withdrawn, this is executed immediately.
Note for the reader Function Manual Basic Functions V1
DB3200
DBX1000.4
DBX1004.4
DBX1008.4
Traversing key disable
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The plus and minus traversing keys have no effect on the geometry axes in
question. It is thus not possible to traverse the geometry axis in JOG with
the traversing keys on the machine control panel.
If the traversing
key disable is activated while traversing, the geometry axis
is stopped.
Signal state 0 The plus and minus traversing keys are enabled.
Application It is thus possible, depending on the operating state, to interlock traversing
of the geometry axis in JOG mode using the traversing keys from the PLC
user program.
corresponding to ... IS "Traversing key plus" and " ... minus"
for axis 1 in the Work (DB3200 DBX1000.7 and .6 )
for axis 2 in the Work (DB3200 DBX1004.7 and .6 )
for axis 3 in the Work (DB3200 DBX1008.7 and .6 )
Note for the reader Function Manual Basic Functions H1
DB3200
DBX1000.5
DBX1004.5
DBX1008.5
Rapid traverse override
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.7 Channel-specific signals
