DB3300
DBX4006.0
ASUP active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 One ASUP is active.
Signal state 0 No ASUP is active.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX4006.0
ASUP active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 An ASUP with suppressed display update is active (refer to MD20191).
Signal state 0 No ASUP with suppressed display update is active.
Corresponding to ... MD20191 IGN_PROG_STATE_ASUP
(do not display execution of the interrupt program on the OPI)
Note for the reader Function Manual Basic Functions K1
DB3500
DBB0 - 63
Active G function of groups 1 to 64
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Event-controlled
Signal status > 1 A G function of the G group is active.
The
active
G
group is saved in the dual format in the byte involved, e.g. G90:
0 1 0 1 1 0 1 0
Signal state 0 No G function of the G group is active.
Special cases, er‐
rors, ...
In contrast to auxiliary functions, G functions are not output to the PLC subject
to acknowledgement, i.e. processing of the part program is continued imme‐
diately after the G function output.
Note for the reader Programming Manual, Fundamentals
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
List Manual, 01/2017 423
