DB390x
DBX2.2
Revolutional feedrate active
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 When programming G95 (revolutional feedrate) in the JOG mode or auto‐
matic mode.
corresponding to ... SD41100 JOG_REV_IS_ACTIVE
(revolutional feedrate for JOG active)
SD42600 JOG_FEED_PER_REV_SOURCE
(In the JOG mode revolutional feedrate for geometry axes, on which the
frame with rotation acts)
SD43300 ASSIGN_FEED_PER_REV_SOURCE
(Revolutional feedrate for position axes/spindles)
MD32040 JOG_REV_VELO_RAPID
(Revolutional feedrate for JOG with rapid traverse override)
MD32050 JOG_REV_VELO (revolutional feedrate for JOG)
Note for the reader Function Manual, Expansion Functions P2
Function Manual, Special Functions M3
DB390x
DBX2.3
Measurement active
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The "Measuring" function is active.
The instantaneous measurement
status of the axis is displayed (measuring
set with this axis is running).
Signal state 0 The "Measuring" function is not active.
Note for the reader Function Manual, Expansion Functions M5
DB390x
DBX2.4
Activate travel to fixed endstop
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The "Travel to fixed stop" function is active.
Signal state 0 The "Travel to fixed stop" function is not active.
Note for the reader Function Manual Basic Functions F1
DB390x
DBX2.5
Fixed stop reached
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The fixed stop was reached after selecting the "FXS" function.
Signal state 0 The fixed stop has still not been reached after selecting the "FXS" function.
Note for the reader Function Manual Basic Functions F1
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
List Manual, 01/2017 453
