11 Activate channel-specific protection zone
Area 10 Area 9
12
13 Do not
block tool
Deactivate
workpiece
counter
Activate fixed feedrate
Feed 4 Feed 3 Feed 2 Feed 1
14 No tool
change
commands
JOG circle Activate as‐
sociated
M01
Negative di‐
rection for
contour
handwheel
simulation
Simulate
contour
handwheel
Activate contour handwheel (bit/binary
coded)
Handwheel
2
Handwheel
1
15 Activate
skip block 9
Activate
skip block 8
Invert con‐
tour hand‐
wheel
direc‐
tion
16 Program
branches
(GOTOS)
control
17
18
19
1)
Select single-block type selection using the softkey.
2)
31 positions (Gray code)
Controls signals to axes in Work
DB3200 Signals to NCK channel [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Axis 1 in Work
Traversing keys Rapid tra‐
verse over‐
ride
Traversing
key dis‐
tance disa‐
ble
Feedrate
stop
Activate handwheel (bit/binary coded)
1)
Plus Minus 2 1
1001 Axis 1 in Work
Machine function
2)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1002
1003
Handwheel
direction of
rotation in‐
verted
PLC user interface
6.10 Channel signals
Parameter Manual
List Manual, 01/2017 491
