Siemens SINUMERIK 808D Parameter Manual

Signals from drive
DB3900 ...
3903
Signals from axis/spindle [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
4000 Holding
brake
opened
RLI active
4001 Pulse ena‐
bled
Speed con‐
troller inte‐
grator disa‐
bled
Drive ready
4002 nact = n
set
n
act
< n
x
n
act
< n
min
M
d
< M
dx
Ramp-up
completed
4003 Generator
operation,
minimum
speed fal‐
led below
VDClink <
alarm
threshold
Signals from technology functions
DB3900 ...
3903
Signals from axis/spindle [r]
NCK -> PLC interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
5000
5001
5002 Accelera‐
tion warn‐
ing thresh‐
old reached
Velocity
warning
threshold
reached
Superim‐
posed mo‐
tion
Actual val‐
ue coupling
Synchronous operation
Coarse Fine
5003 Max. accel‐
eration
reached
Max. veloci‐
ty reached
Synchroni‐
zation in
progress
Axis is ac‐
celerating
Synchron‐
ism over‐
ride travel
5004
5005
5006
5007 Synchron‐
ism over‐
ride is fac‐
tored in
5008 (grind‐
ing)
Active special axis
Axis 6 Axis 5 Axis 4 Axis 3 Axis 2 Axis 1
PLC user interface
6.11 Axis/spindle signals
Parameter Manual
List Manual, 01/2017 501
