On the first NCK power-up or cold restart of the control (=deletion of user data)
MD18230 $MN_MM_USER_MEM_BUFFERED is set by the NCK software so that at least the
default value results for MD18060 $MN_INFO_FREE_MEM_STATIC.
Machine data for configuration of functions that require nonvolatile memory (tools,
GUDs, compensations, ...) can be increased until this memory has all been allocated.
18082 MM_NUM_TOOL N02, N09 FBWsl, S7
- Number of tools the NCK can manage (SRAM) DWORD PowerOn
-
808d-me42 - 64 0 64 ReadOnly S
808d-me62 - 64 0 64 ReadOnly S
808d-te42 - 64 0 64 ReadOnly S
808d-te62 - 64 0 64 ReadOnly S
808d-mte40 - - 0 128 ReadOnly S
808d-mte60 - - 0 128 ReadOnly S
Description: The NC cannot manage more tools than the number entered in the MD. A tool has at least
one cutting edge.
Buffered user memory is used.
The maximum possible number of tools is equal to the number of cutting edges. The MD
must also be set when TOOLMAN is not used.
The buffered data are lost when the machine data is changed.
Related to:
18094 MM_NUM_CC_TDA_PARAM N02, N09 H2
- Number of OEM tool data (SRAM) DWORD PowerOn
-
- - 0 0 64 2/2 M
Description: Number of tool-specific data (of type Integer) which can be created per tool, and which
are available to the user or the compile cycle.
This machine data increases the buffered memory requirement by sizeof(double)*max.
number of tools.
Related to:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK
MD18082 $MN_MM_NUM_TOOL
18095 MM_TYPE_CC_TDA_PARAM N02, N09 -
- Type of OEM tool data (SRAM) DWORD PowerOn
-
808d-me42 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 ReadOnly M
808d-me62 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 ReadOnly M
808d-te42 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 ReadOnly M
808d-te62 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 ReadOnly M
808d-mte40 64 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
808d-mte60 64 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2 M
Description: Individual types can be assigned to the parameters in this way. The array index n can
accept values from 0 to the value of MD18094 $MN_MM_NUM_CC_TDA_PARAM.
The possible values of the MD = 1, 2, 3, 4, 5 and 6 represent the NC language types
1 BOOL,
2 CHAR,
3 INT,
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 93
