No. Parameter
mask
Parameter
internal
Data type Meaning
17 <_VARI> INT Machining type
UNITS:
1 = Roughing
2 = Finishing
4 = Edge finishing
5 = Chamfering
TENS:
0 = Predrilled, infeed with G0
1 = Vertically, infeed with G1
2 = Helical
3 = Oscillation on pocket longitudinal
axis
HUNDREDS: Reserved
18 DXY <_MIDA> REAL Maximum plane infeed, for unit, see <_AMODE>
19 L1 <_AP1> REAL Length of premachining (inc)
20 W1 <_AP2> REAL Width of premachining (inc)
21 AZ <_AD> REAL Depth of premachining (inc)
22 ER <_RAD1> REAL
Radius of helical path on helical insertion
EW Maximum insertion angle for oscillation
23 EP <_DP1> REAL Helical pitch on helical insertion
24 <_UMODE> INT Reserved
25 FS <_FS> REAL Chamfer width (inc)
26 ZFS <_ZFS> REAL Insertion depth (tool tip) on chamfering (abs/inc), see <_AMODE>
Work preparation
3.25 Programming cycles externally
NC programming
1030 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
