No. Parameter
mask
Parameter
internal
Data type Meaning
27 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining/only calculation of start
point
0 = Compatibility mode
1 = Normal machining
THOUSANDS: Dimensioning via center/corner
0 = Compatibility mode
1 = Dimensioning via center
2 = Dimensioning of corner point,
pocket position +LENG/+WID
3 = Dimensioning of corner point,
pocket position -LENG/+WID
4 = Dimensioning of corner point,
pocket position +LENG/-WID
5 = Dimensioning of corner point,
pocket position -LENG/-WID
TEN THOUSANDS: Complete machining/remachining
0 = Compatibility mode
(process <_AP1>, <_AP2>
and <_AD> as before)
1 = Complete machining
2 = Post machining
28 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of feedrate: G group (G94/G95) for
surface and depth feedrate
0 = Compatibility mode
1 = G command as before cycle call.
G94/G95 same for surface and
depth feedrate
HUNDREDS: --- Reserved
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1031
