No. Parameter
mask
Parameter
internal
Data type Meaning
34 Coolant on <S_CON> STRING[10] Coolant on, M command or subprogram call
35 Coolant off <S_COFF> STRING[10] Coolant off, M command or subprogram call
36 <_GMODE> INT
Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Drilling depth with respect to tip/shank
0 = Tip
1 = Shank
37 <_DMODE> INT
Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Basic
Work preparation
3.25 Programming cycles externally
NC programming
1104 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
