No. Parameter
mask
Parameter
internal
Data type Meaning
38 <_AMODE> INT
Alternative mode 1
UNITS: Drilling depth = Final drilling depth Z1
abs/inc
0 = Incremental
1 = Absolute
TENS: Dwell time at each drilling depth DTB in
seconds/revolutions
0 = In seconds
1 = In revolutions
HUNDREDS: Dwell time for chip removal DTS in sec‐
onds/revolutions
0 = In seconds
1 = In revolutions
THOUSANDS: Dwell time at final drilling depth DT in
seconds/revolutions
0 = In seconds
1 = In revolutions
TEN THOUSANDS: 1st drilling depth D abs/inc
0 = Incremental
1 = Absolute
HUNDRED THOUSANDS: Absolute value / percentage DF for each
additional infeed (degression)
0 = Absolute value
1 = Percentage (0.001 to 100%)
ONE MILLION: Limit distance V3 automatic/manual
0 = Automatic (calculated in the cy‐
cle)
1 = Manual (programmed value)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1105
