Siemens SINUMERIK 840DE SL - Page 1436

Commissioning the system
1.2 User administration
PCU-Basesoftware (IM8)
16 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
"Startup (2)" tab
Figure 1-4 "Startup (2)" tab
Table 1- 2 The default is marked in "
bold
".
Startup (2) tab
Option
Effect
Keys, filtering
Enable
"yes"
Key filtering is activated.
"no"
Key filtering not activated.
Filter file
E:\WINDOWS\System.ini
Select the file with filter settings
Desktop Logon
Start dialog:
"yes"
Display "Desktop Access" dialog
"no"
Do not display "Desktop Access" dialog
Logon Dialog:
"yes"
Display "Desktop Logon" dialog.
"no"
Do not display "Desktop Logon" dialog.
Default password map:
"no"
The password must be entered exactly as
specified.
"yes"
The password is not case-sensitive.
Authentication:
"manual"
Authentication with user name and
password (manual)
"EKS"
Authentication with EKS
"manual+EKS" Either authentication with user name and
password or with EKS
