Base
Slot Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Base AB n + 0 KT-OUT8
X515.20
KT-OUT7
X515.19
KT-OUT6
X515.18
KT-OUT5
X515.17
KT-OUT4
X515.16
KT-OUT3
X515.15
KT-OUT2
X515.14
KT-OUT1
X515.13
AB n + 1 KT-OUT16
X516.20
KT-OUT15
X516.19
KT-OUT14
X516.18
KT-OUT13
X516.17
KT-OUT12
X516.16
KT-OUT11
X516.15
KT-OUT10
X516.14
KT-OUT9
X516.13
Key modules
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Key module 1 AB n + 0 LED key module 1
LED8 LED7 LED6 LED5 LED4 LED3 LED2 LED1
AB n + 1 LED key module 1
LED15 LED14 LED13 LED12 LED11 LED10 LED9
AB n + 2 LED key module 1.1
LED18 LED17 LED16
AB n + 3 LED key module 1.2
LED26 LED25 LED24
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Key module 2 AB n + 0 LED key module 2
LED8 LED7 LED6 LED5 LED4 LED3 LED2 LED1
AB n + 1 LED key module 2
LED15 LED14 LED13 LED12 LED11 LED10 LED9
AB n + 2 LED key module 2.1
LED18 LED17 LED16
AB n + 3 LED key module 2.2
LED26 LED25 LED24
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Key module 3 AB n + 0 LED key module 3
LED8 LED7 LED6 LED5 LED4 LED3 LED2 LED1
AB n + 1 LED key module 3
LED15 LED14 LED13 LED12 LED11 LED10 LED9
AB n + 2 LED key module 3.1
LED18 LED17 LED16
AB n + 3 LED key module 3.2
LED26 LED25 LED24
Connecting
5.3 Output images
ONE MCP Part 1: MCP xxxx
48 Equipment Manual, 07/2020, A5E50324729B AA
