Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Key module 4 AB n + 0 LED key module 4
LED8 LED7 LED6 LED5 LED4 LED3 LED2 LED1
AB n + 1 LED key module 4
LED15 LED14 LED13 LED12 LED11 LED10 LED9
AB n + 2 LED key module 4.1
LED18 LED17 LED16
AB n + 3 LED key module 4.2
LED26 LED25 LED24
*): The logical address is made up of the oset and the start address from the hardware
conguration.
Powerrides
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Powerride 1 AB n + 0 Powerride 1 LED scale
LED 24
AB n + 1 Powerride 1 LED scale
LED23 LED22 LED21 LED20 LED19 LED18 LED17 LED16
AB n + 2 Powerride 1 LED scale
LED15 LED14 LED13 LED12 LED11 LED10 LED9 LED8
AB n + 3 Powerride 1 LED scale
LED7 LED6 LED5 LED4 LED3 LED2 LED1 LED0
AB n + 4 Powerride 1 start button Powerride 1 color scale
Green Blue Green Red
AB n + 5 Vibration pattern
2
2
2
1
2
0
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Powerride 2 AB n + 0 Powerride 2 LED scale
LED 24
AB n + 1 Powerride 2 LED scale
LED23 LED22 LED21 LED20 LED19 LED18 LED17 LED16
AB n + 2 Powerride 2 LED scale
LED15 LED14 LED13 LED12 LED11 LED10 LED9 LED8
AB n + 3 Powerride 2 LED scale
LED7 LED6 LED5 LED4 LED3 LED2 LED1 LED0
AB n + 4 Powerride 2 start button Powerride 2 color scale
Green Blue Green Red
AB n + 5 Vibration pattern
2
2
2
1
2
0
Connecting
5.3 Output images
