Siemens SIPROTEC 7SJ62 User Manual

Functions
2.13 Intermittent Ground Fault Protection
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
246
Table 2-16 Unrestricted Messages
Table 2-17 shows all messages subject to a restraint mechanism avoiding a message burst during an intermit-
tent ground fault:
Table 2-17 Buffered Messages
FNo. Message Description
1800 „50-2 picked up“ 50-2 picked up
2642 „67-2 picked up“ 67-2 picked up
7551 „50-1 InRushPU“ 50-1 InRush picked up
7552 „50N-1 InRushPU“ 50N-1 InRush picked up
7553 „51 InRushPU“ 51 InRush picked up
7554 „51N InRushPU“ 51N InRush picked up
7559 „67-1 InRushPU“ 67-1 InRush picked up
7560 „67N-1 InRushPU“ 67N-1 InRush picked up
7561 „67-TOC InRushPU“ 67-TOC InRush picked up
7562 „67N-TOCInRushPU“ 67N-TOC InRush picked up
7565 „Ia InRush PU“ Phase A InRush picked up
7566 „Ib InRush PU“ Phase B InRush picked up
7567 „Ic InRush PU“ Phase C InRush picked up
7564 „Gnd InRush PU“ Ground InRush picked up
FNo. Message Explanation
1761 „50(N)/51(N) PU“ 50(N)/51(N) picked up
1762 „50/51 Ph A PU“ 50/51 Phase A picked up
1763 „50/51 Ph B PU“ 50/51 Phase B picked up
1764 „50/51 Ph C PU“ 50/51 Phase C picked up
1810 „50-1 picked up“ 50-1 picked up
1820 „51 picked up“ 51 picked up
1765 „50N/51NPickedup“ 50N/51N picked up
1831 „50N-2 picked up“ 50N-2 picked up
1834 „50N-1 picked up“ 50N-1 picked up
1837 „51N picked up“ 51N picked up
2691 „67/67N pickedup“ 67/67N picked up
2660 „67-1 picked up“ 67-1 picked up
2670 „67-TOC pickedup“ 67-TOC picked up
2692 „67 A picked up“ 67/67-TOC Phase A picked up
2693 „67 B picked up“ 67/67-TOC Phase B picked up
2694 „67 C picked up“ 67/67-TOC Phase C picked up
2646 „67N-2 picked up“ 67N-2 picked up
2681 „67N-1 picked up“ 67N-1 picked up
2684 „67N-TOCPickedup“ 67N-TOC picked up
2695 „67N picked up“ 67N/67N—TOC picked up
5159 „46-2 picked up“ 46-2 picked up
5165 „46-1 picked up“ 46-1 picked up
5166 „46-TOC pickedup“ 46-TOC picked up
1215 „64 Pickup“ 64 displacement voltage pick up
1221 „50Ns-2 Pickup“ 50Ns-2 picked up
1224 „50Ns-1 Pickup“ 50Ns-1 picked up
