2.18 Reverse-Power Protection Application with Flexible Protection Function
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
304
Allocating the Reverse-Power Protection in DIGSI Configuration Matrix
The DIGSI configuration matrix initially shows the following indications (after selecting „Indications and com-
mands only“ and „No filter“, Figure 2-114):
Figure 2-114 Indications prior to editing
Clicking the texts allows for editing short text and long text as required by the application (Figure 2-115):
Figure 2-115 Indications after editing
The indications are allocated in the same way as the indications of other protective functions.
