Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
414
Power Supply
Table 3-12 Jumper setting of the nominal voltage of the integrated power supply on the processor module
C-CPU-2
1)
230 VAC only possible for release 7SJ64**-.../CC and higher
Live Status Contact
Table 3-13 Jumper position of the quiescent state of the live status contact on the C-CPU-2 processor
printed circuit board
Pickup Voltages of BI1 to BI5
Table 3-14 Jumper settings of the Pickup Voltages (DC voltage) of the binary inputs BI1 to BI5 on the
C-CPU-2 processor board
1)
Factory settings for devices with power supply voltages of 24 to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 to 250 VDC and 115 VAC or 115 to 230 VAC
3)
Use only with pickup voltages 220 or 250 VDC
Jumper Rated Voltage
24 to 48 VDC 60 to 125 VDC 110 to 250 VDC,
115 to 230 VAC
1)
X51 not used 1-2 2-3
X52 not used 1-2 and 3-4 2-3
X53 not used 1-2 2-3
X55 not used not used 1-2
not changeable interchangeable
Jumper Open in the quiescent state Closed in the quiescent state Presetting
X40 1-2 2-3 2-3
Binary Inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
176 VDC Pickup
3)
BI1 X21 1-2 2-3 3-4
BI2 X22 1-2 2-3 3-4
BI3 X23 1-2 2-3 3-4
BI4 X24 1-2 2-3 3-4
BI5 X25 1-2 2-3 3-4
