Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
424
Input / Output Board C-I/O-4 (7SJ647)
The layout of the printed circuit board for the input/output board C–I/O-4 is illustrated in the following figure.
The selected pickup voltages of the binary inputs BI6 to BI20 are checked according to Table 3-14.
Figure 3-18 Input/output module C–I/O-4 with representation of the jumper settings required for the module
configuration
