Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
427
Table 3-29 Exchangeable interface modules
1)
for 7SJ64 Port C / service port is fix, it is not a plug-in module
The order numbers of the exchange modules can be found in the Appendix in Section A.1, Accessories.
Interface Mounting Loca-
tion / Port
Exchange Module
System Interface
(7SJ62/64)
B
IEC 60870–5–103 RS232
IEC 60870–5–103 RS485
IEC 60870–5–103 redundant
RS485
FO 820 nm
Profibus FMS RS 485
Profibus FMS double ring
Profibus FMS single ring
Profibus DP RS485
Profibus DP double ring
Modbus RS485
Modbus 820 nm
DNP 3.0 RS485
DNP 3.0 820 nm
IEC 61850 Ethernet electrical
IEC 61850 Ethernet optical
DIGSI / Modem Interface / RTD-box (7SJ62)
1)
C
RS232
RS485
FO 820 nm
Additional Interface / RTD-box (7SJ64) D
RS485
FO 820 nm
