Technical Data
4.1 General Device Data
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
469
Binary Outputs
1)
FLA = “Full Load Ampere”
2)
High-duty relays are used for the direct activation of motor-driven switches. The high-duty relays operate in
an interlocked mode, i.e. only one binary output of each pair of switches is activated, thus avoiding a short-
circuit of the power supply. When used as a standard relay, only one binary output of a pair can be used.
Permanent operation is not specified.
Output relay for commands/annunciations, alarm relay
*),
, high-duty relay
**) 2)
Number and Information According to the order variant (allocatable);
values in (): up to release .../DD
Order Variant NO contact
*
) NO/NC selectable
*
) high-duty relay
**)
2)
7SJ621*- 6 (8) 3 (1) –
7SJ622*- 4 (6) 3 (1) –
7SJ623*- 6 (8) 3 (1) –
7SJ624*- 4 (6) 3 (1) –
7SJ640*- 5 1 –
7SJ641*- 12 2 –
7SJ642*- 8 1 4
7SJ645*- 11 1 8
7SJ647*- 21 1 8
Switching Capability MAKE 1000 W/VA –
Switching Capability BRAKE 30 VA 40 W resistive 25 W
at L/R ≤ 50 ms
–
Switching Voltage 250 VDC / VAC 250 VDC / VAC
admissible current per contact (continuous) 5 A –
admissible current per contact (close and hold) 30 A for 0.5 s (NO contact)
Total current on common path 5 A continuous, 30 A for 0.5 s –
max. switching capability for 30 s
at 48 V to 250 V
at 24 V
–
1000 W
500 W
Permissible relative closing time – 1 %
AC Load (it has to be taken into consideration for the dimensions of external circuits)
Value of the ANSI capacitor:
4.70· 10
-9
F ± 20%
Frequency Impedance
50 Hz 6.77· 10
5
Ω ± 20%
60 Hz 5.64· 10
5
Ω ± 20%
*)
UL–listed with the Following Nominal Values:
120 VAC Pilot duty, B300
240 VAC Pilot duty, B300
240 VAC 5 A general purpose
24 VDC 5 A general purpose
48 VDC 0.8 A general purpose
240 VDC 0.1 A general purpose
120 VAC 1/6 hp (4.4 FLA
1)
)
240 VAC 1/2 hp (4.9 FLA
1)
)
**)
UL–listed with the Following Nominal Values:
240 VDC 1.6 FLA
1)
120 VDC 3.2 FLA
1)
60 VDC 5.5 FLA
1)
