Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
554
1)
Cannot be delivered in connection with 9th digit = "B". If the optical interface is required you must order the
following: 11. digit = 4 (RS485) and in addition, the associated converter.
2)
Cannot be delivered in connection with 9th digit = "B".
1)
The converter requires an operating voltage of 24 VDC. If the available operating voltage is > 24 VDC the
additional power supply 7XV5810–0BA00 is required.
1)
RTD-box 7XV5662–*AD10
System Interface (Rear Side, Port B) Pos. 11
No system interface 0
IEC 60870-5-103 Protocol, electrical RS232 1
IEC 60870-5-103 Protocol, electrical RS485 2
IEC 60870-5-103 Protocol, optical 820 nm, ST-connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, optical, Single Ring, ST-Connector
1)
5
1)
Profibus FMS Slave, optical, Double Ring, ST-Connector
1)
6
1)
For further interface options see Additional Information in the following L 9
Additional information L to further system interfaces (device rear, port B) Supple-
mentary
Profibus DP Slave, RS485 + L 0 A
Profibus DP Slave, 820 nm, optical double ring, ST–connector
1)
+ L 0 B
1)
Modbus RS 485 + L 0 D
Modbus, 820 nm, optical, ST–connector
2)
+ L 0 E
2)
DNP3.0, RS 485 + L 0 G
DNP3.0, 820 nm, optical, ST–connector
2)
+ L 0 H
2)
IEC 60870-5-103 protocol, redundant, electrical RS485, RJ45-connector
2)
+ L 0 P
2)
IEC 61850, Ethernet electrical, double, RJ45–connector (EN 100) + L 0 R
IEC 61850, Ethernet optical, double, ST-connector (EN 100)
2)
+ L 0 S
2)
Converter Order No. Use
SIEMENS OLM
1)
6GK1502–2CB10 For single ring
SIEMENS OLM
1)
6GK1502–3CB10 For double ring
DIGSI/Modem Interface (Rear Side, Port C) Pos. 12
DIGSI/Modem, electrical RS232 1
DIGSI/Modem/RTD box
1)
, electrical RS485 2
For further interface options see Additional Information M 9
