A.1 Ordering Information and Accessories
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
555
1)
RTD-box 7XV5662–*AD10
2)
If you want to run the RTD box on an optical port, you will also need the RS485 optical converter 7XV5650–
0*A00.
Additional Information M, Service and Additional Interface (Port C and Port D)
Port C: DIGSI/Modem, electrical RS232 M 1 *
Port C: DIGSI/Modem/RTD box
1)
, electrical RS485 M 2 *
Port D: RTD box
1)
, optical 820 nm,
2)
, ST connector M * A
Port D: RTD-Box
1)
, electrical RS485 M * F
Measuring/Fault Recording Pos. 13
With fault recording 1
With fault recording, average values, min/max values 3
Functions Pos. 14
and 15
Designation ANSI No. Description F A
Basic Elements (included in all ver-
sions)
— Control
50/51 Time overcurrent protection phase 50-1, 50-2, 50-3, 51
50N/51N Ground fault protection ground 50N-1, 50N-2, 50N-3,
51N
50N/51N Insensitive time overcurrent protection ground via the
insensitive DGFD function: 50Ns-1, 50Ns-2, 51Ns
50/50N Flexible protection functions (parameters from current):
additive overcurrent time protection 50-4
51V Voltage-controlled time overcurrent protection
49 Overload protection (with 2 time constants)
46 Negative sequence protection
37 Undercurrent monitoring
47 Phase rotation
64/59N Displacement voltage
50BF Circuit breaker failure protection
74TC Trip circuit monitoring
— Cold-load pickup (dynamic setting changes) 50C-1,
50C-2, 50NC-1, 50NC-2, 51NC
— Inrush restraint
86 Lock out
V, f, P 27/59
81O/U
27/47/59(N)/
32/55/81R
Under/Overvoltage 59-1, 59-2, 27-1, 27-2
Under/Overfrequency
Flexible protection functions (parameters from current
and voltage): Voltage, power, power factor, frequency
change protection
F E
IEF V, f, P 27/59
81O/U
27/47/59(N)/
32/55/81R
—
Under/Overvoltage 59-1, 59-2, 27-1, 27-2
Under/Overfrequency
Flexible protection functions (parameters from current
and voltage): Voltage, power, power factor, frequency
change protection
Intermittent ground fault
P E
Dir 67/67N Directional overcurrent protection F C
