Siemens SIPROTEC 7SJ62 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
633
1308 51N TIME DIAL 50/51 Overcur. 0.05 .. 3.20 sec; ∞ 0.20 sec 51N Time Dial
1309 51N TIME DIAL 50/51 Overcur. 0.50 .. 15.00 ; ∞ 5.00 51N Time Dial
1310 51N Drop-out 50/51 Overcur. Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1311 51N IEC CURVE 50/51 Overcur. Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1312 51N ANSI CURVE 50/51 Overcur. Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1313A MANUAL CLOSE 50/51 Overcur. 50N-3 instant.
50N-2 instant.
50N-1 instant.
51N instant.
Inactive
50N-2 instant. Manual Close Mode
1314A 50N-2 active 50/51 Overcur. Always
With 79 Active
Always 50N-2 active
1315A 50N T DROP-OUT 50/51 Overcur. 0.00 .. 60.00 sec 0.00 sec 50N Drop-Out Time Delay
1316A 50N-3 active 50/51 Overcur. Always
with 79 active
Always 50N-3 active
1317 50N-3 PICKUP 50/51 Overcur. 0.25 .. 35.00 A; ∞∞A 50N-3 Pickup
1318 50N-3 DELAY 50/51 Overcur. 0.00 .. 60.00 sec; ∞ 0.00 sec 50N-3 Time Delay
1319A 50N-3 measurem. 50/51 Overcur. Fundamental
True RMS
Instantaneous
Fundamental 50N-3 measurement of
1320A 50N-2 measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 50N-2 measurement of
1321A 50N-1 measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 50N-1 measurement of
1322A 51N measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 51N measurement of
1330 50N/51N 50/51 Overcur. 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
50N/51N
1331 MofPU Res T/TEp 50/51 Overcur. 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> T/TEp
1501 FCT 67/67-TOC 67 Direct. O/C OFF
ON
OFF 67, 67-TOC Phase Time Over-
current
1502 67-2 PICKUP 67 Direct. O/C 1A 0.10 .. 35.00 A; ∞ 2.00 A 67-2 Pickup
5A 0.50 .. 175.00 A; ∞ 10.00 A
1503 67-2 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.10 sec 67-2 Time Delay
1504 67-1 PICKUP 67 Direct. O/C 1A 0.10 .. 35.00 A; ∞ 1.00 A 67-1 Pickup
5A 0.50 .. 175.00 A; ∞ 5.00 A
1505 67-1 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.50 sec 67-1Time Delay
1507 67-TOC PICKUP 67 Direct. O/C 1A 0.10 .. 4.00 A 1.00 A 67-TOC Pickup
5A 0.50 .. 20.00 A 5.00 A
1508 67 TIME DIAL 67 Direct. O/C 0.05 .. 3.20 sec; ∞ 0.50 sec 67-TOC Time Dial
1509 67 TIME DIAL 67 Direct. O/C 0.50 .. 15.00 ; ∞ 5.00 67-TOC Time Dial
1510 67-TOC Drop-out 67 Direct. O/C Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1511 67- IEC CURVE 67 Direct. O/C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1512 67- ANSI CURVE 67 Direct. O/C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
De
finite Inv.
Very Inverse ANSI Curve
Addr. Parameter Function C Setting Options Default Setting Comments
