A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
634
1513A MANUAL CLOSE 67 Direct. O/C 67-2 instant.
67-1 instant.
67-TOC instant.
Inactive
67-2 instant. Manual Close Mode
1514A 67-2 active 67 Direct. O/C with 79 active
always
always 67-2 active
1516 67 Direction 67 Direct. O/C Forward
Reverse
Forward Phase Direction
1518A 67 T DROP-OUT 67 Direct. O/C 0.00 .. 60.00 sec 0.00 sec 67 Drop-Out Time Delay
1519A ROTATION ANGLE 67 Direct. O/C -180 .. 180 ° 45 ° Rotation Angle of Reference
Voltage
1520A 67-2 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-2 measurement of
1521A 67-1 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-1 measurement of
1522A 67-TOC MEASUR. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-TOC measurement of
1530 67 67 Direct. O/C 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
67
1531 MofPU Res T/Tp 67 Direct. O/C 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> T/Tp
1601 FCT 67N/67N-TOC 67 Direct. O/C OFF
ON
OFF 67N, 67N-TOC Ground Time
Overcurrent
1602 67N-2 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.50 A 67N-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
1603 67N-2 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.10 sec 67N-2 Time Delay
1604 67N-1 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.20 A 67N-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
1605 67N-1 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.50 sec 67N-1 Time Delay
1607 67N-TOC PICKUP 67 Direct. O/C 1A 0.05 .. 4.00 A 0.20 A 67N-TOC Pickup
5A 0.25 .. 20.00 A 1.00 A
1608 67N-TOC T-DIAL 67 Direct. O/C 0.05 .. 3.20 sec; ∞ 0.20 sec 67N-TOC Time Dial
1609 67N-TOC T-DIAL 67 Direct. O/C 0.50 .. 15.00 ; ∞ 5.00 67N-TOC Time Dial
1610 67N-TOC DropOut 67 Direct. O/C Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1611 67N-TOC IEC 67 Direct. O/C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1612 67N-TOC ANSI 67 Direct. O/C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1613A MANUAL CLOSE 67 Direct. O/C 67N-2 instant.
67N-1 instant.
67N-TOC instant
Inactive
67N-2 instant. Manual Close Mode
1614A 67N-2 active 67 Direct. O/C always
with 79 active
always 67N-2 active
1616 67N Direction 67 Direct. O/C Forward
Reverse
Forward Ground Direction
1617 67N POLARIZAT. 67 Direct. O/C with VN and IN
with V2 and I2
with VN and IN Ground Polarization
1618A 67N T DROP-OUT 67 Direct. O/C 0.00 .. 60.00 sec 0.00 sec 67N Drop-Out Time Delay
1619A ROTATION ANGLE 67 Direct. O/C -180 .. 180 ° -45 ° Rotation Angle of Reference
Voltage
1620A 67N-2 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-2 measurement of
1621A 67N-1 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-1 measurement of
1622A 67N-TOC MEASUR. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-TOC measurement of
Addr. Parameter Function C Setting Options Default Setting Comments
