Appendix
A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
639
4311 ROTOR OVERLOAD 48/66 Motorprot ON
OFF
Alarm Only
ON Rotor Overload Protection
4401 Load Jam Prot. 48/66 Motorprot OFF
ON
Alarm Only
OFF Load Jam Protection
4402 Load Jam I> 48/66 Motorprot 1A 0.50 .. 12.00 A 2.00 A Load Jam Tripping Threshold
5A 2.50 .. 60.00 A 10.00 A
4403 TRIP DELAY 48/66 Motorprot 0.00 .. 600.00 sec 1.00 sec Load Jam Trip Delay
4404 I Alarm 48/66 Motorprot 1A 0.50 .. 12.00 A 1.80 A Load Jam Alarm Threshold
5A 2.50 .. 60.00 A 9.00 A
4405 ALARM DELAY 48/66 Motorprot 0.00 .. 600.00 sec 1.00 sec Load Jam Alarm Delay
4406 T Start Blk. 48/66 Motorprot 0.00 .. 600.00 sec 10.00 sec Load Jam Blocking after motor
start
5001 FCT 59 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 59 Overvoltage Protection
5002 59-1 PICKUP 27/59 O/U Volt. 40 .. 260 V 110 V 59-1 Pickup
5003 59-1 PICKUP 27/59 O/U Volt. 40 .. 150 V 110 V 59-1 Pickup
5004 59-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; 0.50 sec 59-1 Time Delay
5005 59-2 PICKUP 27/59 O/U Volt. 40 .. 260 V 120 V 59-2 Pickup
5006 59-2 PICKUP 27/59 O/U Volt. 40 .. 150 V 120 V 59-2 Pickup
5007 59-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; 0.50 sec 59-2 Time Delay
5015 59-1-V2 PICKUP 27/59 O/U Volt. 2 .. 150 V 30 V 59-1 Pickup Overvoltage (neg.
seq.)
5016 59-2-V2 PICKUP 27/59 O/U Volt. 2 .. 150 V 50 V 59-2 Pickup Overvoltage (neg.
seq.)
5017A 59-1 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-1 Dropout Ratio
5018A 59-2 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-2 Dropout Ratio
5019 59-1 PICKUP V1 27/59 O/U Volt. 40 .. 150 V 110 V 59-1 Pickup V1
5020 59-2 PICKUP V1 27/59 O/U Volt. 40 .. 150 V 120 V 59-2 Pickup V1
5101 FCT 27 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 27 Undervoltage Protection
5102 27-1 PICKUP 27/59 O/U Volt. 10 .. 210 V 75 V 27-1 Pickup
5103 27-1 PICKUP 27/59 O/U Volt. 10 .. 120 V 75 V 27-1 Pickup
5106 27-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; 1.50 sec 27-1 Time Delay
5110 27-2 PICKUP 27/59 O/U Volt. 10 .. 210 V 70 V 27-2 Pickup
5111 27-2 PICKUP 27/59 O/U Volt. 10 .. 120 V 70 V 27-2 Pickup
5112 27-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; 0.50 sec 27-2 Time Delay
5113A 27-1 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-1 Dropout Ratio
5114A 27-2 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-2 Dropout Ratio
5120A CURRENT SUPERV. 27/59 O/U Volt. OFF
ON
ON Current Supervision
5201 VT BROKEN WIRE Measurem.Superv ON
OFF
OFF VT broken wire supervision
5202 Σ V> Measurem.Superv 1.0 .. 100.0 V 8.0 V Threshold voltage sum
5203 Vph-ph max< Measurem.Superv 1.0 .. 100.0 V 16.0 V Maximum phase to phase
voltage
5204 Vph-ph min< Measurem.Superv 1.0 .. 100.0 V 16.0 V Minimum phase to phase voltage
5205 Vph-ph max-min> Measurem.Superv 10.0 .. 200.0 V 16.0 V Symmetry phase to phase volt-
ages
5206 I min> Measurem.Superv 1A 0.04 .. 1.00 A 0.04 A Minimum line current
5A 0.20 .. 5.00 A 0.20 A
5208 T DELAY ALARM Measurem.Superv 0.00 .. 32.00 sec 1.25 sec Alarm delay time
5301 FUSE FAIL MON. Measurem.Superv OFF
Solid grounded
Coil.gnd./isol.
OFF Fuse Fail Monitor
5302 FUSE FAIL 3Vo Measurem.Superv 10 .. 100 V 30 V Zero Sequence Voltage
Addr. Parameter Function C Setting Options Default Setting Comments
