A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
640
5303 FUSE FAIL RESID Measurem.Superv 1A 0.10 .. 1.00 A 0.10 A Residual Current
5A 0.50 .. 5.00 A 0.50 A
5307 I> BLOCK Measurem.Superv 0.10 .. 35.00 A; ∞ 1.00 A I> Pickup for block FFM
5310 BLOCK PROT. Measurem.Superv NO
YES
YES Block protection by FFM
5401 FCT 81 O/U 81 O/U Freq. OFF
ON
OFF 81 Over/Under Frequency Pro-
tection
5402 Vmin 81 O/U Freq. 10 .. 150 V 65 V Minimum required voltage for op-
eration
5403 81-1 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 49.50 Hz 81-1 Pickup
5404 81-1 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 59.50 Hz 81-1 Pickup
5405 81-1 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 60.00 sec 81-1 Time Delay
5406 81-2 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 49.00 Hz 81-2 Pickup
5407 81-2 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 59.00 Hz 81-2 Pickup
5408 81-2 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 30.00 sec 81-2 Time Delay
5409 81-3 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 47.50 Hz 81-3 Pickup
5410 81-3 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 57.50 Hz 81-3 Pickup
5411 81-3 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 3.00 sec 81-3 Time delay
5412 81-4 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 51.00 Hz 81-4 Pickup
5413 81-4 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 61.00 Hz 81-4 Pickup
5414 81-4 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 30.00 sec 81-4 Time delay
5415A DO differential 81 O/U Freq. 0.02 .. 1.00 Hz 0.02 Hz Dropout differential
5421 FCT 81-1 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-1 Over/Under Frequency Pro-
tection
5422 FCT 81-2 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-2 Over/Under Frequency Pro-
tection
5423 FCT 81-3 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-3 Over/Under Frequency Pro-
tection
5424 FCT 81-4 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-4 Over/Under Frequency Pro-
tection
6001 S1: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S1: Zero seq. compensating
factor RE/RL
6002 S1: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S1: Zero seq. compensating
factor XE/XL
6003 S1: x' P.System Data 2 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S1: feeder reactance per mile: x'
6004 S1: x' P.System Data 2 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S1: feeder reactance per km: x'
6005 S1: Line angle P.System Data 2 10 .. 89 ° 85 ° S1: Line angle
6006 S1: line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles S1: Line length in miles
6007 S1: Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km S1: Line length in kilometer
6011 S2: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S2: Zero seq. compensating
factor RE/RL
6012 S2: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S2: Zero seq. compensating
factor XE/XL
6013 S2: x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S2: feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6014 S2: x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S2: feeder reactance per km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6015 S2: Line angle P.System Data 2 10 .. 89 ° 85 ° S2: Line angle
6016 S2: line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles S2: line length in miles
6017 S2: Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km S2: Line length in kilometer
6021 S3: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S3: Zero seq. compensating
factor RE/RL
6022 S3: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S3: Zero seq. compensating
factor XE/XL
6023 S3: x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S3: feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
