Siemens SIPROTEC 7SJ62 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
663
177 Failure: Battery empty (Fail Bat-
tery)
Device, General OUT On
Off
**LEDBO
178 I/O-Board Error (I/O-Board error) Device, General OUT On
Off
**LEDBO
181 Error: A/D converter (Error A/D-
conv.)
Device, General OUT On
Off
**LEDBO
183 Error Board 1 (Error Board 1) Device, General OUT On
Off
**LEDBO
184 Error Board 2 (Error Board 2) Device, General OUT On
Off
**LEDBO
185 Error Board 3 (Error Board 3) Device, General OUT On
Off
**LEDBO
186 Error Board 4 (Error Board 4) Device, General OUT On
Off
**LEDBO
187 Error Board 5 (Error Board 5) Device, General OUT On
Off
**LEDBO
188 Error Board 6 (Error Board 6) Device, General OUT On
Off
**LEDBO
189 Error Board 7 (Error Board 7) Device, General OUT On
Off
**LEDBO
191 Error: Offset (Error Offset) Device, General OUT On
Off
**LEDBO
192 Error:1A/5Ajumper different from
setting (Error1A/5Awrong)
Device, General OUT On
Off
*
193 Alarm: NO calibration data avail-
able (Alarm NO calibr)
Device, General OUT On
Off
**LEDBO
194 Error: Neutral CT different from
MLFB (Error neutralCT)
Device, General OUT On
Off
*
197 Measurement Supervision is
switched OFF (MeasSup OFF)
Measurem.Superv OUT On
Off
* * LED BO 135 197 1 Yes
203 Waveform data deleted (Wave.
deleted)
Osc. Fault Rec. OUT_
Ev
on * LED BO 135 203 1 No
220 Error: Range CT Ph wrong (CT
Ph wrong)
Device, General OUT On
Off
*
234.2100 27, 59 blocked via operation (27,
59 blk)
27/59 O/U Volt. IntSP On
Off
**LEDBO
235.2110 >BLOCK Function $00 (>BLOCK
$00)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2111 >Function $00 instantaneous
TRIP (>$00 instant.)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2112 >Function $00 Direct TRIP (>$00
Dir.TRIP)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2113 >Function $00 BLOCK TRIP
Time Delay (>$00 BLK.TDly)
Flx SP On
Of
f
On
Off
**LEDBIFC
TN
BO
235.2114 >Function $00 BLOCK TRIP
(>$00 BLK.TRIP)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2115 >Function $00 BLOCK TRIP
Phase A (>$00 BL.TripA)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2116 >Function $00 BLOCK TRIP
Phase B (>$00 BL.TripB)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2117 >Function $00 BLOCK TRIP
Phase C (>$00 BL.TripC)
Flx SP On
Off
On
Off
**LEDBIFC
TN
BO
235.2118 Function $00 is BLOCKED ($00
BLOCKED)
Flx OUT On
Off
On
Off
**LED BO
235.2119 Function $00 is switched OFF
($00 OFF)
Flx OUT On
Off
* * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
