Appendix
A.9 Information List
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
664
235.2120 Function $00 is ACTIVE ($00
ACTIVE)
Flx OUT On
Off
* * * LED BO
235.2121 Function $00 picked up ($00
picked up)
Flx OUT On
Off
On
Off
**LED BO
235.2122 Function $00 Pickup Phase A
($00 pickup A)
Flx OUT On
Off
On
Off
**LED BO
235.2123 Function $00 Pickup Phase B
($00 pickup B)
Flx OUT On
Off
On
Off
**LED BO
235.2124 Function $00 Pickup Phase C
($00 pickup C)
Flx OUT On
Off
On
Off
**LED BO
235.2125 Function $00 TRIP Delay Time
Out ($00 Time Out)
Flx OUT On
Off
On
Off
**LED BO
235.2126 Function $00 TRIP ($00 TRIP) Flx OUT On
Off
on * * LED BO
235.2128 Function $00 has invalid settings
($00 inval.set)
Flx OUT On
Off
On
Off
**LED BO
236.2127 BLOCK Flexible Function (BLK.
Flex.Fct.)
Device, General IntSP On
Off
* * * LED BO
253 Failure VT circuit: broken wire
(VT brk. wire)
Measurem.Superv OUT On
Off
**LEDBO
255 Failure VT circuit (Fail VT circuit) Measurem.Superv OUT On
Off
**LEDBO
256 Failure VT circuit: 1 pole broken
wire (VT b.w. 1 pole)
Measurem.Superv OUT On
Off
**LEDBO
257 Failure VT circuit: 2 pole broken
wire (VT b.w. 2 pole)
Measurem.Superv OUT On
Off
**LEDBO
258 Failure VT circuit: 3 pole broken
wire (VT b.w. 3 pole)
Measurem.Superv OUT On
Off
**LEDBO
264 Failure: RTD-Box 1 (Fail: RTD-
Box 1)
RTD-Box OUT On
Off
**LEDBO
267 Failure: RTD-Box 2 (Fail: RTD-
Box 2)
RTD-Box OUT On
Off
**LEDBO
268 Supervision Pressure (Su-
perv.Pressure)
Measurement OUT On
Off
**LEDBO
269 Supervision Temperature (Su-
perv.Temp.)
Measurement OUT On
Off
**LEDBO
270 Set Point Pressure< (SP. Pres-
sure<)
Set Points(MV) OUT On
Off
**
LEDBO
271 Set Point Temp> (SP. Temp>) Set Points(MV) OUT On
Off
**LEDBO
272 Set Point Operating Hours (SP.
Op Hours>)
SetPoint(Stat) OUT On
Off
* * LED BO 135 229 1 Yes
273 Set Point Phase A dmd> (SP. I A
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 230 1 Yes
274 Set Point Phase B dmd> (SP. I B
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 234 1 Yes
275 Set Point Phase C dmd> (SP. I C
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 235 1 Yes
276 Set Point positive sequence
I1dmd> (SP. I1dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 236 1 Yes
277 Set Point |Pdmd|> (SP. |Pdmd|>) Set Points(MV) OUT On
Off
* * LED BO 135 237 1 Yes
278 Set Point |Qdmd|> (SP. |Qdmd|>) Set Points(MV) OUT On
Off
* * LED BO 135 238 1 Yes
279 Set Point |Sdmd|> (SP. |Sdmd|>) Set Points(MV) OUT On
Off
* * LED BO 135 239 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
