A.11 Measured Values
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
684
603 Ic (Ic =) Measurement 134 137 No 9 3 CFC CD DD
604 In (In =) Measurement 134 137 No 9 4 CFC CD DD
605 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
606 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
621 Va (Va =) Measurement 134 137 No 9 5 CFC CD DD
622 Vb (Vb =) Measurement 134 137 No 9 6 CFC CD DD
623 Vc (Vc =) Measurement 134 137 No 9 7 CFC CD DD
624 Va-b (Va-b=) Measurement 160 145 Yes 3 2 CFC CD DD
134 137 No 9 8
625 Vb-c (Vb-c=) Measurement 134 137 No 9 9 CFC CD DD
626 Vc-a (Vc-a=) Measurement 134 137 No 9 10 CFC CD DD
627 VN (VN =) Measurement 134 118 No 9 1 CFC CD DD
629 V1 (positive sequence) (V1 =) Measurement - - - - - CFC CD DD
630 V2 (negative sequence) (V2 =) Measurement - - - - - CFC CD DD
632 Vsync (synchronism) (Vsync =) Measurement - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 137 No 9 11 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 137 No 9 12 CFC CD DD
644 Frequency (Freq=) Measurement 134 137 No 9 13 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ REST. =) Measurement - - - - - CFC CD DD
701 Resistive ground current in isol systems (INs
Real)
Measurement 134 137 No 9 15 CFC CD DD
702 Reactive ground current in isol systems (INs
Reac)
Measurement 134 137 No 9 16 CFC CD DD
805 Temperature of Rotor (Θ Rotor) Measurement - - - - - CFC CD DD
807 Thermal Overload (Θ/Θtrip) Measurement - - - - - CFC CD DD
809 Time untill release of reclose-blocking (T re-
close=)
Measurement - - - - - CFC CD DD
830 INs Senstive Ground Fault Current (INs =) Measurement 134 118 No 9 3 CFC CD DD
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC CD DD
832 Vo (zero sequence) (Vo =) Measurement 134 118 No 9 2 CFC CD DD
833 I1 (positive sequence) Demand (I1 dmd=) Demand meter - - - - - CFC CD DD
834 Active Power Demand (P dmd =) Demand meter - - - - - CFC CD DD
835 Reactive Power Demand (Q dmd =) Demand meter - - - - - CFC CD DD
836 Apparent Power Demand (S dmd =) Demand meter - - - - - CFC CD DD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CFC CD DD
838 I A Demand Maximum (IAdmdMax) Min/Max meter - - - - - CFC CD DD
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CFC CD DD
840 I B Demand Maximum (IBdmdMax) Min/Max meter - - - - - CFC CD DD
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CFC CD DD
842 I C Demand Maximum (ICdmdMax) Min/Max meter - - - - - CFC CD DD
843 I1 (positive sequence) Demand Minimum
(I1dmdMin)
Min/Max meter - - - - - CFC CD DD
844 I1 (positive sequence) Demand Maximum
(I1dmdMax)
Min/Max meter - - - - - CFC CD DD
845 Active Power Demand Minimum (PdMin=) Min/Max meter - - - - - CFC CD DD
846 Active Power Demand Maximum (PdMax=) Min/Max meter - - - - - CFC CD DD
847 Reactive Power Demand Minimum (QdMin=) Min/Max meter - - - - - CFC CD DD
848 Reactive Power Demand Maximum (Qd-
Max=)
Min/Max meter - - - - - CFC CD DD
849 Apparent Power Demand Minimum (SdMin=) Min/Max meter - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
