Siemens SIPROTEC 7SJ62 User Manual

Appendix
A.11 Measured Values
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
685
850 Apparent Power Demand Maximum (Sd-
Max=)
Min/Max meter - - - - - CFC CD DD
851 Ia Min (Ia Min=) Min/Max meter - - - - - CFC CD DD
852 Ia Max (Ia Max=) Min/Max meter - - - - - CFC CD DD
853 Ib Min (Ib Min=) Min/Max meter - - - - - CFC CD DD
854 Ib Max (Ib Max=) Min/Max meter - - - - - CFC CD DD
855 Ic Min (Ic Min=) Min/Max meter - - - - - CFC CD DD
856 Ic Max (Ic Max=) Min/Max meter - - - - - CFC CD DD
857 I1 (positive sequence) Minimum (I1 Min=) Min/Max meter - - - - - CFC CD DD
858 I1 (positive sequence) Maximum (I1 Max=) Min/Max meter - - - - - CFC CD DD
859 Va-n Min (Va-nMin=) Min/Max meter - - - - - CFC CD DD
860 Va-n Max (Va-nMax=) Min/Max meter - - - - - CFC CD DD
861 Vb-n Min (Vb-nMin=) Min/Max meter - - - - - CFC CD DD
862 Vb-n Max (Vb-nMax=) Min/Max meter - - - - - CFC CD DD
863 Vc-n Min (Vc-nMin=) Min/Max meter - - - - - CFC CD DD
864 Vc-n Max (Vc-nMax=) Min/Max meter - - - - - CFC CD DD
865 Va-b Min (Va-bMin=) Min/Max meter - - - - - CFC CD DD
867 Va-b Max (Va-bMax=) Min/Max meter - - - - - CFC CD DD
868 Vb-c Min (Vb-cMin=) Min/Max meter - - - - - CFC CD DD
869 Vb-c Max (Vb-cMax=) Min/Max meter - - - - - CFC CD DD
870 Vc-a Min (Vc-aMin=) Min/Max meter - - - - - CFC CD DD
871 Vc-a Max (Vc-aMax=) Min/Max meter - - - - - CFC CD DD
872 V neutral Min (Vn Min =) Min/Max meter - - - - - CFC CD DD
873 V neutral Max (Vn Max =) Min/Max meter - - - - - CFC CD DD
874 V1 (positive sequence) Voltage Minimum (V1
Min =)
Min/Max meter - - - - - CFC CD DD
875 V1 (positive sequence) Voltage Maximum
(V1 Max =)
Min/Max meter - - - - - CFC CD DD
876 Active Power Minimum (Pmin=) Min/Max meter - - - - - CFC CD DD
877 Active Power Maximum (Pmax=) Min/Max meter - - - - - CFC CD DD
878 Reactive Power Minimum (Qmin=) Min/Max meter - - - - - CFC CD DD
879 Reactive Power Maximum (Qmax=) Min/Max meter - - - - - CFC CD DD
880 Apparent Power Minimum (Smin=) Min/Max meter - - - - - CFC CD DD
881 Apparent Power Maximum (Smax=) Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fmin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fmax=) Min/Max meter - - - - - CFC CD DD
884 Power Factor Maximum (PF Max=) Min/Max meter - - - - - CFC CD DD
885 Power Factor Minimum (PF Min=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CFC CD DD
901 Power Factor (PF =) Measurement 134 137 No 9 14 CFC CD DD
924 Wp Forward (WpForward) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (WqForward) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (WpReverse) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (WqReverse) Energy 133 54 No 205 - CFC CD DD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD DD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD DD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD DD
991 Pressure (Press =) Measurement - - - - - CFC CD DD
992 Temperature (Temp =) Measurement - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
