Operating principle
The 3RW55 and 3RW55 Failsafe soft starters record service data during starting and stopping.
If problems occur in the system in conjunction with the 3RW55 or 3RW55 Failsafe soft starter,
you can save the service data on the micro SD card. The service data can help Technical Support
to handle the case in the event of a Support Request (Page 11). The service data contain the
following data, for example:
• Parameters
• Logbooks
• Statistic data
• Maximum pointer
• I&M data
Procedure
Save the service data on the 3RW5 HMI High Feature onto the micro SD card.
Menu: "Micro SD card > Save service data to micro SD card"
Saving the service data can take a little time (> 1 minute). At the top level of the micro SD card,
a folder is created with the serial number of the 3RW55 or 3RW55 Failsafe soft starter in which
the service data is stored. Example of a created folder name: "1P3RW5 xxx-xxxxx+SLO..."
Note
Save service data to micro SD card
While the service data are being saved to the micro SD card, the color of the micro SD card icon
changes from blue to red on the display 3RW5 HMI High Feature. If the service data have been
saved completely, the color of the icon changes back to blue.
Icon of the micro SD card on the display of the 3RW5 HMI High Feature:
Result
You have stored the service data on the micro SD card.
These service data can help Technical Support to handle the case in the event of a Support
Request (Page 11). If necessary, read the micro SD card in at a PC and send the folder of service
data as a ZIP le.
Messages and diagnostics
9.11 Save service data to micro SD card
SIRIUS 3RW55 and 3RW55 Failsafe Soft Starters
Equipment Manual, 02/2022, A5E35630887002A/RS-AF/006 267
