Procedure for removal
DANGER
Hazardous voltage.
Will cause death or serious injury.
Turn o and lock out all power supplying this device before working on this device.
Illustration similar
• Pry the box terminal block o the main circuit connections ① / ②.
• Pull the box terminal block o the main circuit connections ③.
Connecting
5.6 Replacement of the box terminal blocks with size 2
SIRIUS 3RW55 and 3RW55 Failsafe Soft Starters
Equipment Manual, 02/2022, A5E35630887002A/RS-AF/006 79
