Siemens Sivacon S8 Planning Information

43
SIVACON S8 Planning Principles – Universal mounting design
2
3
4
5
6
7
8
9
10
11
1
Fig. 4/11: Front areas usable for an instrument panel on small withdrawable units with an installation height of 150 mm
94
38
105
109
38
104
Dimensions in mm
Size: ¼ Size: ½
Fig. 4/12: Front areas usable for an instrument panel on small withdrawable units with an installation height of 200 mm
94
88
105
159
88
104
Dimensions in mm
Size: ¼ Size: ½
Fig. 4/13: Front areas usable for an instrument panel on normal withdrawable units
190 190
96
51.5
Dimensions in mm
Height of withdrawable unit 100 mm
Height of withdrawable unit > 100 mm
