Scale parameters and functions
8.13 DR 13 RS485 parameters
SIWAREX WP251
Manual, 12/2015, A5E37203357A
101
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
RS485
baud rate
(Page 102)
0: 1 200 bps
1: 2 400 bps
2: 9 600 bps
3: 19 200 bps
4: 38 400 bps
5: 57 600 bps
6:115 000 bps
USHORT 2 rw 2 0 6 1563
RS485
character
parity
(Page 102)
Character parity
0: Even
1: Odd
BIT 0 rw 0 0 1 1564.16
RS485
number of
data bits
(Page 102)
Number of data bits per
character
0: 7 data bits
1: 8 data bits
BIT 0 rw 0 0 1 1564.15
RS485
number of
stop bits
(Page 103)
Number of stop bits
0: 1 stop bit
1: 2 stop bits
BIT 0 rw 0 0 1 1564.14
Bit 3
Reserve
BIT
0
rw
0
0
1
1564.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1564.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1564.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1564.10
Bit 7
Reserve
BIT
0
rw
0
0
1
1564.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1564.8
Bit 9 Reserve BIT 0 rw 0 0 1 1564.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1564.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1564.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1564.4
Bit 13
Reserve
BIT
0
rw
0
0
1
1564.3
Bit 14
Reserve
BIT
0
rw
0
0
1
1564.2
Bit 15
Reserve
BIT
2
rw
0
0
1
1564.1
RS485
Modbus
address
(Page 103)
MODBUS address for Vito
module
USHORT 2 rw 20 1 255 1565
Decimal
place for
Siebert
indicator
(Page 103)
Decimal place for Siebert
display
SHORT 2 rw 0 - - 1566
MODBUS
RTU frame
delay
Delay time for response with
MODBUS RTU in ms
(RS485)
USHORT 2 rw 0 - - 1567
Reserve 3
Reserve
FLOAT
4
rw
0
-
-
1568
