Page #159 background imageLoading...
Page #159 background image
Scale parameters and functions
8.37 DR 47 Logbook
SIWAREX WP251
Manual, 12/2015, A5E37203357A
159
Designation
Data type
Length
Additional string
UBYTE
16
SEMICOLON UBYTE 1
8.36.6
Date, time
The date and time of the selected log are displayed here.
8.37
DR 47 Logbook
The changes in the SecureDisplay software versions are recorded in the logbook. If the
SIWAREX has established communication with the SecureDisplay, SIWAREX checks
whether the software version of the SecureDisplay has changed. Changes are recorded in
the logbook. In this way, a more recent version of the SecureDisplay can also be used during
operation requiring calibration without the calibration being violated.
The logbook entries are in data record 47. Scrolling in the logbook is possible using
commands 881 to 883: → Command list (page 135). Calibratable reading of the logbook is
carried out using the SecureDisplay.
Table 8- 38 Assignment of data record 47
Tag
Comments
Type
Length
(bytes)
Rw
De-
fault
Min.
Max.
Modbus
register
Data record number
Contains no. of the data
record
USHORT
2
r
47
4392
Length
Data record length infor-
mation
USHORT
2
r
72
4393
Application
Information about which
ap
plication the data record
belongs to
USHORT
2
r
105
4394
Version identifier
Current data record ver-
sion information
USHORT
2
r
1
1
65635
4395
String header for oldest log
book ID
String header UBYTE[2] 2 r 8,8 4396
Oldest log book ID
ID of first logbook entry
CHAR[8]
8
r
"0"
1
99999999
4397
String header of youngest
logbook ID
String header UBYTE[2] 2 r 8,8 4401
Youngest logbook-ID
ID of last logbook entry
CHAR[8]
8
r
"0"
1
99999999
4402
String header for selected
logbook ID
String header UBYTE[2] 2 r 8,8 4406
ID of the selected logbook
entry
ID of the selected logbook
entry
CHAR[8] 8 r "0" 1 99999999 4407
String header for device
String header
UBYTE[2]
2
r
4,4
4411
