SIWAREX WP251
Manual, 12/2015, A5E37203357A
197
Operation requiring official calibration
12
12.1
Preparing for calibration
12.1.1
Calibration set
The calibration set (available as Accessory (Page 213)) with the following contents is
available for operation requiring verification:
SecureDisplay software for legal trade display of weight
Ready-to-use project for TIA portal and TP 700 Comfort operator panel
Manual
Information on use of the module in operation requiring verification
EC construction license for the module
Test certificates for the displays
Calibration plate for covering the connection terminals
Templates for ID labels
Tags for ID labels
Self-adhesive markers "M" (green and red)
You can prepare the scale verification using the calibration set.
12.1.2
Scale design
If you wish to use the scale in operation requiring verification, the design must correspond to
the conditions specified in the construction license. Therefore you should already take the
specifications of the construction license into account when configuring and designing the
scale. In the case of calibrated scales, the responsible weights and measures office should
be contacted in advance in order to clarify the type of scale and other matters.
12.1.3
Installation and parameter assignment of the calibratable SecureDisplay main
display in the HMI
The SIWAREX SecureDisplay software serves as the legal trade main display of the scale.
The software must be installed on the HMI prior to the verification.
You can find a complete description of the software installation in the "SIWAREX
SecureDisplay" information in Siemens Industry Online Support at
(https://support.industry.siemens.com/cs/ww/de/view/109477602
).
