Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.31 DR 35 SecureDisplay data
SIWAREX WP251
Manual, 12/2015, A5E37203357A
151
Tare weight (via command 705 for 5 seconds)
From DR 30
Restriction code (via command 801 for 5 seconds)
From DR 3
Set point (via command 721 for 5 seconds)
From DR 20
Total set point (via command 722 for 5 seconds)
From DR 21
Totalizer 1 (via command 771 for 5 seconds) From DR 30
Totalizer 2 (via command 772 for 5 seconds)
From DR 30
Serial number of WP251 (via command 871 for 5 seconds)
From DR 9
Firmware version of WP251 (via command 875 for 5 seconds)
From DR 9
SecureDisplay version (via command 876 for 5 seconds)
From DR 3
8.31
DR 35 SecureDisplay data
For a scale requiring official calibration in which "SecureDisplay" communicates with WP251
via the CPU, data record 35 provides the coded weight value. In this case it must be ensured
that the data record is read from SIWAREX to the CPU in a fixed time grid (OB 35) using
command code 2035. If this is not the case, "SecureDisplay" remains in "StartUp" state. For
applications not requiring official calibration, DR 35 is not relevant to the operation of the
scale.
Table 8- 31 Assignment of data record 35
Variable
Remark
Type
Length
(bytes)
Rw
Default
Min.
Max.
Data record number
Contains no. of the data record
USHORT
2
r
35
-
-
Length
Data record length information
USHORT
2
r
40
-
-
Application Information about which applica-
tion the DR belongs to
USHORT 2 r 105 - -
Version identifier Current data record version in-
formation
USHORT 2 r 1 1 65635
SecureDisplayData
UBYTE[32]
32
r
0
-
-
