Siemens SIWAREX WP251 - Connection of Digital Outputs (4 X DQ); Image 6-5 Connection of Strain Gauge Load Cell with 6-Wire System; Image

Connection
6.5 Connection of digital outputs (4 x DQ)
SIWAREX WP251
34 Manual, 12/2015, A5E37203357A
Image 6-5 Connection of strain gauge load cell with 6-wire system
6.5
Connection of digital outputs (4 x DQ)
CAUTION
Unknown assignment of digital outputs
The assignment of the digital outputs is not known at the time of connection. Digital outputs
can be active immediately after turning on the power supply. This may damage parts of the
system.
Do not create a connection with the digital outputs before you know the assignment of the
digital outputs.
