Scale parameters and functions
8.12 DR 12 Ethernet parameters
SIWAREX WP251
98 Manual, 12/2015, A5E37203357A
8.11.3
Load cell characteristic value
The load cell characteristic value is required to correctly interpret the output voltage from the
load cell. When Siemens WL series load cells are used, the exact characteristic value can be
read from label on the cell. If the exact characteristic value of the utilized cell(s) is not
available, a rounded value can also be specified. For scales with multiple load cells, the
average of all load cells must be calculated and entered.
Example
Characteristic value according to load cell label = 2.018 mV/V
→ Characteristic value = 2.018 mV/V
If this exact value is not known, 2.0 mV/V could also be entered.
8.11.4
Rated load of a load cell
The nominal load is entered in the specified weight units The parameter is required for
automatic calculation of the scale characteristic curve (command 82).
8.12
DR 12 Ethernet parameters
8.12.1
Overview
Before the SIWAREX module can be integrated into an Ethernet network, the Ethernet
parameters must be adapted, if necessary. The IP address, subnet, gateway and device
name can be changed or adapted in DR 12.
Table 8- 11 Assignment of data record 12
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of the data
record
USHORT 2 r 12 - - 1500
Length Data record length infor-
mation
USHORT 2 r 116 - - 1501
Application Information about which
application the DR belongs
to
USHORT 2 r 105 - - 1502
Version identifi-
er
Current data record version
information
USHORT 2 r 1 1 65635 1503
Device MAC
address
(Page 99)
Device MAC address 1
USHORT
2
r
0
255
1504
Device MAC address 2
USHORT
2
r
0
255
1505
Device MAC address 3
USHORT
2
r
0
255
1506
Device MAC address 4
USHORT
2
r
0
255
1507
Device MAC address 5
USHORT
2
r
0
255
1508
