8.28 DR 31 Process state extended
SIWAREX WP251
Manual, 12/2015, A5E37203357A
143
Variable
Note
Type
Length
(bytes)
RW
De-
fault
Min.
Max.
Modbus
registers
Current load cell signal
in mV (Page 145)
Voltage signal at load cell
input in mV
FLOAT 4 r 0 - - 3316
Current fine weight
(Page 145)
Current fine weight (ad-
justed by the controller)
FLOAT 4 r 0 0 65535 3318
Current trailing weight
(Page 145)
Current trailing weight
(adjusted by the controller)
FLOAT 4 r 0 0 65535 3320
Reserve Reserve FLOAT 4 r 0 0 65535 3322
Reserve
Reserve
FLOAT
4
r
0
0
65535
3324
Reserve
Reserve
FLOAT
4
r
0
0
65535
3326
Reserve
Reserve
FLOAT
4
r
0
0
65535
3328
Tolerance limits TH2,
TH1, TL1 and TL2
(Page 145)
High limit tolerance band 2
(absolute weight value)
FLOAT 4 r 0 0 65535 3330
Tolerance limits TH2,
TH1, TL1 and TL2
(Page 145)
High limit tolerance band 1
(absolute weight value)
FLOAT 4 r 0 0 65535 3332
Tolerance limits TH2,
TH1, TL1 and TL2
(Page 145)
Low limit tolerance band 1
(absolute weight value)
FLOAT 4 r 0 0 65535 3334
Tolerance limits TH2,
TH1, TL1 and TL2
(Page 145)
Low limit tolerance band 2
(absolute weight value)
FLOAT 4 r 0 0 65535 3336
Reserve
Reserve
USHORT
2
r
0
0
65535
3338
Reserve
Reserve
USHORT
2
r
0
0
65535
3339
Reserve
Reserve
FLOAT
4
r
0
-
-
3340
Reserve
Reserve
FLOAT
4
r
0
-
-
3342
8.28.2
Unfiltered digit value
The unfiltered digit value is the internal measured value before filtering.
8.28.3
Digits filtered by F1
The filtered digit value is the internal measured value after filtering with filters defined in DR
3.
8.28.4
Filtered digit value 2
The filtered digit value is the internal measured value after filtering with filters defined in DR
24.
