Scale parameters and functions
8.28 DR 31 Process state extended
SIWAREX WP251
142 Manual, 12/2015, A5E37203357A
Variable
Note
Type
Length
(bytes)
RW
De-
fault
Min.
Max.
Modbus
registers
Filtered digit value 2
(Page 143)
Filtered value after filter 2
(DR 24)
LONG 4 r 0 - - 3308
Current analog output
(mA) (Page 144)
Currently output analog
output value in mA
FLOAT 4 r 0 0 10000 3310
Current analog output
(digits) (Page 144)
Currently output analog
output value in digits
USHORT 2 r 0 0 10000 3312
Reserve Reserve USHORT 2 r 0 0 10000 3313
Current status digital
input DI.0, DI.1, DI.2
and DI.3 (Page 144)
Current status of input 0 B16_0 0 r 0 - - 3314
Current status digital
input DI.0, DI.1, DI.2
and DI.3 (Page 144)
Current status of input 1 B16_1 0 r 0 - - 3314
Current status digital
input DI.0, DI.1, DI.2
and DI.3 (Page 144)
Current status of input 2 B16_2 0 r 0 - - 3314
Current status digital
input DI.0, DI.1, DI.2
and DI.3 (Page 144)
Current status of input 3 B16_3 0 r 0 - - 3314
Reserve
Reserve
B16_4
0
r
0
-
-
3314
Reserve
Reserve
B16_5
0
r
0
-
-
3314
DIP switch 1 and 2
(Page 144)
Set when switch 1 is
closed
B16_6 0 r 0 - - 3314
DIP switch 1 and 2
(Page 144)
Set when switch 2 is
closed
B16_7 1 r 0 - - 3314
Current status digital
output DQ.0, DQ.1,
DQ.2 and DQ.3
(Page 144)
Current status of output 0 B16_8 0 r 0 - - 3314
Current status digital
output DQ.0, DQ.1,
DQ.2 and DQ.3
(Page 144)
Current status of output 1 B16_9 0 r 0 - - 3314
Current status digital
output DQ.0, DQ.1,
DQ.2 and DQ.3
(Page 144)
Current status of output 2 B16_10 0 r 0 - - 3314
Current status digital
output DQ.0, DQ.1,
DQ.2 and DQ.3
(Page 144)
Current status of output 3 B16_11 0 r 0 - - 3314
Reserve
Reserve
B16_12
0
r
0
-
-
3314
Reserve Reserve B16_13 0 r 0 - - 3314
Reserve
Reserve
B16_14
0
r
0
-
-
3314
Reserve Reserve B16_15 1 r 0 - - 3314
Refresh counter
(Page 144)
Refresh counter USHORT 2 r 0 0x0000 0xFFFF 3315
