Scale parameters and functions
8.27 DR 30 Process state
SIWAREX WP251
136 Manual, 12/2015, A5E37203357A
Table 8- 27 Assignment of data record 30
Variable
Note
Type
Length
(bytes)
RW
De-
fault
Min.
Max.
Modbus
regis-
ters
Data record number Contains no. of the data
record
USHORT 2 r 30 - - 3000
Length Data record length infor-
mation
USHORT 2 r 112 - - 3001
Application
Information on application to
which DR belongs
USHORT 2 r 105 - - 3002
Version identifier
Current data record version
information
USHORT 2 r 1 1 65535 3003
NAWI
Status
1/4d zero Set if gross is less than ±
0.25 d
B16_0 0 r 0 - - 3004
Out of weighing
range
Set if the gross weighing
range is exceeded more
than 9 display increments or
is fallen below more than -
20 display increments
B16_1 0 r 0 - - 3004
Tared Set when tare weight is
active
B16_2 0 r 0 - - 3004
Preset tare active Set when preset tare weight
is active
B16_3 0 r 0 - - 3004
Reserve
Reserve
B16_4
0
r
0
-
-
3004
Waiting for standstill
1
Set when module is waiting
for standstill to execute
command
B16_5 0 r 0 - - 3004
Standstill 1 Set when standstill condi-
tion 1 is met
B16_6 0 r 0 - - 3004
Reserve
Reserve
B16_7
1
r
0
-
-
3004
Empty
Limit 3 (status empty)
B16_8
0
r
0
-
-
3004
Limit 1
Limit value 1 has responded
B16_9
0
r
0
-
-
3004
Limit 2
Limit value 2 has responded
B16_10
0
r
0
-
-
3004
< Minimum weight Minimum weighing range
fallen below
B16_11 0 r 0 - - 3004
Reserve
Reserve
B16_12
0
r
0
-
-
3004
Reserve
Reserve
B16_13
0
r
0
-
-
3004
Reserve
Reserve
B16_14
0
r
0
-
-
3004
Reserve
Reserve
B16_15
1
r
0
-
-
3004
Reserve
Reserve
B16_0
0
r
0
-
-
3005
Reserve
Reserve
B16_1
0
r
0
-
-
3005
Reserve
Reserve
B16_2
0
r
0
-
-
3005
Reserve
Reserve
B16_3
0
r
0
-
-
3005
Reserve
Reserve
B16_4
0
r
0
-
-
3005
