Scale parameters and functions
8.23 DR 24 Controller and filter parameters
SIWAREX WP251
122 Manual, 12/2015, A5E37203357A
Maximum cor-
rective action
Maximum corrective action in
weight unit
FLOAT 4 rw 5 > 0 0 1704
Controller dead-
band - upper
limit (Page 124)
Upper limit of controller deadband
(if the dosed weight is within the
controller deadband, no further
FLOAT 4 rw 0 0 0 1706
Controller dead-
band - lower limit
(Page 124)
Lower limit of controller deadband
(if the dosed weight is within the
controller deadband, no further
FLOAT 4 rw 0 0 0 1708
Reaction when
max. corrective
action is ex-
ceeded
0: Discontinue control
1: Control up to maximum correc-
tive action
USHORT 2 rw 1 0 0 1710
Selection for
dosing filter
(Page 124)
0: Process values and dosing ac-
cording to filter F1
1: Process values according to
Filter 1, dosing according to Filter 2
USHORT 2 rw 0 0 0 1711
Frequency low
pass filter 2
Limit frequency for low pass filter 2 FLOAT 4 rw 2 - - 1712
Order no. low
pass filter 2
Order number for low pass filter 2 USHORT 2 rw 4 - - 1714
DepthDepth
average filter
Depth of average filter 2 (0 = inac-
tive)
USHORT 2 rw 10 0 250 1715
Adopt corrected
fine/trailing value
to DR 23 auto-
matically
(Page 126)
0= The fine/trailing weight corrected
by the controller is output only in
DR 31 (read-only).
1= The fine/trailing weight corrected
by the controller is output in DR 31
and simultaneously adopted auto-
matically in DR 23 Thus DR 23 is
always updated with the currently
adjusted shut-off points.
USHORT 2 rw 0 0 1 1718
