Siemens SIWAREX WP251 User Manual

Scale parameters and functions
8.27 DR 30 Process state
SIWAREX WP251
138 Manual, 12/2015, A5E37203357A
Variable
Note
Type
Length
(bytes)
RW
De-
fault
Min.
Max.
Modbus
regis-
ters
Aborted
Dosing has been aborted
B16_0
0
r
0
-
-
3007
Step blocked (transi-
tion)
Dosing blocked by step
blocking at digital input or
via S7
B16_1 0 r 0 - - 3007
Above tolerance TH2 Dosed weight above high
tolerance limit TH2 (="Bad")
B16_2 0 r 0 - - 3007
Above tolerance TH1 Dosed weight between high
tolerance limits TH1 and
TH2
B16_3 0 r 0 - - 3007
Good (TL1 to TH1) Dosed weight greater than
TL1 and less than TH1
B16_4 0 r 0 - - 3007
Below tolerance TL1 Dosed weight between low
tolerance limits TL1 and
TL2
B16_5 0 r 0 - - 3007
Below tolerance TL2 Dosed weight below low
tolerance limit TL2 (="Bad")
B16_6 0 r 0 - - 3007
Tolerance bad Dosing is bad / incorrect
weight
B16_7 1 r 0 - - 3007
Standstill 2 Set when scale is within
standstill range 2
B16_8 0 r 0 - - 3007
Waiting for standstill
2
Waiting for standstill 2 for
check
B16_9 0 r 0 - - 3007
Settling time running
before standstill 2
Settling time running before
standstill 2
B16_10 0 r 0 - - 3007
Check follows Current dosing will be
checked
B16_11 0 r 0 - - 3007
Blocking time active Blocking set point/actual
value comparison is running
(no shut-off of dosing sig-
nals occurs during the time)
B16_12 0 r 0 - - 3007
Continuous mode
active
Continuous start is activated B16_13 0 r 0 - - 3007
Weighing cycle fin-
ished
Cycle has finished B16_14 0 r 0 - - 3007
Total set point
reached
Total set point (DR 21) has
been reached
B16_15 1 r 0 - - 3007
Gross, net and tare
process values
(Page 140)
Gross weight (process val-
ue)
FLOAT 4 r 0 - - 3008
Gross, net and tare
process values
(Page 140)
Net weight (process value) FLOAT 4 r 0 - - 3010
Gross, net and tare
process values
(Page 140)
Tare weight (process value) FLOAT 4 r 0 - - 3012
Gross, net and tare
weights (Page 140)
Gross/Net weight rounded
according to DR 3
FLOAT 4 r 0 - - 3014
