Errors and messages
9.6 Operating errors
SIWAREX WP251
166 Manual, 12/2015, A5E37203357A
2003 Initial zero setting on not
possible
2003 The weight at switch-on is outside the configured
value range in data record DR 3 defined by the maxi-
mum positive and negative weight for initial zero set-
2004 Trace memory full 2004 The trace recording has been aborted because the
internal trace memory is full.
2101 Risk of overfilling 2101 Current parameter assignment would lead to overfill-
ing of the scale during dosing. Check the specified set
point in DR 20 or the limits for taring / zero setting in
2102 Coarse shut-off point al-
2102 The current weight is already above the coarse shut-
off point. Remedy: Adjust set point or empty scale.
2104 CPU in "STOP" 2104 WP251 is not in stand-alone operation, the SIMATIC
CPU is in STOP state and a dosing command has
been issued. Remedy: Put the SIMATIC CPU in RUN
state or activate stand-alone operation of WP251.
Ensure the safety of the system before acti-
vating stand-alone operation because WP251 acti-
vates dosing elements if necessary despite the
stopped SIMATIC CPU.
2105 Set point too small 2105 The currently specified set point is too small.
Remedy: Check the set point setting in DR 20.
2106 Error fine weight 2106 Trailing weight (DR 23) and set point (DR 20) are
incompatible. Check the two entries.
2107 Stop after tolerance error 2107 The weighing cycle was stopped due to a tolerance
error according to the parameter assignment in DR 22.
2109 Blocking time "coarse"
error
2109 After expiration of the blocking time coarse signal (DR
23), the coarse shut-off point has already been ex-
ceeded. Remedy: Decrease the blocking time coarse
2110 Blocking time "coarse"
error
2110 After expiration of the blocking time fine signal (DR
23), the fine shut-
off point has already been exceeded.
Remedy: Decrease the blocking time fine signal in DR
2111 Maximum weighing time
exceeded
2111 The maximum weighing time specified in DR 25 was
exceeded.
2112 Logging not possible - no
standstill
2112 The conditions required for automatic logging (e.g.
standstill 2) were not present at the time of the log
print. Remedy: Check the standstill 2 criteria in DR 3
and adapt it as necessary.
2113 Maximum emptying time
exceeded
2113 The maximum emptying time configured in DR 25 was
exceeded during emptying. Remedy: Check the scale
mechanics (for possible soiling). Adjust the maximum
emptying time in DR 25, if necessary.
