Signal Hound BB60C User Manual

G E T T I N G S T A R T E D
11
 Peak Search – This will place the selected marker on the highest amplitude signal on the
trace specified by Place On. If the selected trace is Off then the first enabled trace is used.
 Delta – places a reference marker where the marker currently resides. Once placed you can
make measurements relative to the position of the reference point.
 To Center Freq – changes the center frequency to the frequency location of the selected
marker.
 To Ref Level – changes the reference level to the amplitude of the active marker.
 Peak Left – If the selected marker is active, move the marker to the next peak on the left.
 Peak Right – If the selected marker is active, move the marker to the next peak on the
right.
For peak left/right, peaks are defined by a group of frequency bins 1 standard deviation
above the mean.
Offsets 3.2.1.3
 Ref Offset – Adjust the displayed amplitude to compensate for an attenuator, probe, or
preamplifier.
Channel Power 3.2.1.4
 Width – Specify the width in Hz of the channels to measure.
 Spacing – Specify the center-to-center spacing for each channel.
 Enabled – When enabled, channel power and adjacent channel power measurements will
become active on the screen.
The adjacent and main channels are only displayed when the width and spacing specifies a
channel within the current span. See Taking Measurements: Measuring Channel Power for more
information.
Occupied Bandwidth 3.2.1.5
 Enabled – When enabled, occupied bandwidth measurements will become active on the
screen.
 % Power – Percent power allows the percentage of the integrated power of the occupied
bandwidth measurement to be adjusted.
Sweep Settings 3.2.2
The Sweep Settings control panel controls the sweep acquisition parameters for the device in standard
swept-analysis and real-time modes.
Frequency Controls 3.2.2.1
 Span – controls the frequency difference between the start and stop frequencies centered
on the center frequency. A reduced span will be chosen if the new span causes the start or
