13 BB60A Specifications
Frequency 13.1
Range: 9 kHz to 6.0 GHz
Streaming IF or I/Q data: 20 MHz real-time analysis BW
Resolution Bandwidths (RBW): 10 Hz to 10 MHz
Internal Timebase Accuracy: ±1ppm per year
Sweep Rate 13.2
Sweep Speed (RBW ≥ 9.86 kHz):
(“Spur Reject” off) ≥24 GHz/sec
(“Spur Reject” on) ≥12 GHz/sec
Note: Non-native bandwidths or lower VBWs will result in slower sweep speeds. Sweep speed
does not count sweep setup time (typically <20 ms)
Amplitude (RBW ≤100kHz, IF auto-cal on) 13.3
Range: +10 dBm to Displayed Average Noise Level (DANL)
Absolute Accuracy*: ±2.0 dB
Displayed Average Noise Level (dBm/Hz), reference level -60 dBm, atten 0 dB:
9 kHz to 100 kHz -123
100 kHz to 200 kHz -132
200 kHz to 300 kHz -142
300 kHz to 6 GHz -152
Residual Responses (includes 10 MHz timebase multiples):
(≤ -50 dBm Ref Level, 0 dB Atten) –90 dBm
LO Leakage: ≤ -65 dBm
Please note: native bandwidths have additional “scalloping loss” of up to 0.8 dB. Use non-native (1/3/10)
bandwidths or the channel power tool for critical amplitude measurements.
*Device must be plugged in for at least 5 minutes to guarantee amplitude accuracy.
The window choices allow the user to optimize as needed for best amplitude accuracy, dynamic range, and signal
characteristics.
Note: Window flatness characteristics are not included in the absolute accuracy specification.
