Signal Hound BB60C User Manual

S P E C I F I C A T I O N S
41
12 BB60C Specifications
The following preliminary specifications are based on being in the Preset condition, using internal timebase, video processing set for average
and power, plus VBW, sweep, gain, and attenuation in the default auto mode.
Frequency Range: 9 kHz to 6 GHz
Streaming Digitized I/Q: 250 kHz to 27 MHz of selectable IF bandwidth that is amplitude corrected
Resolution Bandwidths (RBW): 10 Hz to 10 MHz
Internal Timebase Accuracy: ± 1 ppm per year
Sweep Speed (RBW ≥10 kHz): 24 GHz/sec
Amplitude (RBW ≤100 kHz)
Range: +10dBm to Displayed Average Noise Level (DANL)
Absolute Accuracy: ± 2.0 dB (arbitrary & non-native RBW’s)
+ 2.0 dB/-2.6 dB (native RBW’s – faster DSP)
RF Input VSWR at tuned frequency: ≤ 3.0:1 (<10 dB attenuation)
≤ 1.5:1 (≥10 dB attenuation)
LO Leakage at RF Input: -80 dBm
*Displayed Average Noise Level (DANL)
Input Frequency Range
dBm/Hz
9 kHz to 500 kHz
-140
500 kHz to 10 MHz
-154
10 MHz to 6 GHz
-158 + 1.1d B/GHz
*Residual Responses: Ref Level ≤ -50 dBm, 0 dB Attenuation
Input Frequency Range
Residual Level
500 kHz to 6 GHz
-106 dBm
*Spurious Mixer Responses: -50 dBc
(any ref level from +10dBm to -50dBm, in 5dB increments,
input signal 10 dB below ref level, and ≤30kHz RBW)
*SSB Phase Noise at 1 GHz
Center Frequency
Offset Frequency
dBc/Hz
100 Hz
-70
1 kHz
-76
10 kHz
-83
100 kHz
-93
1 MHz
-117
Recommended Computer
Windows® 7 or 8 operating system, 8 GB of RAM, Intel i7, 3
rd
generation (Ivy Bridge) or later with a quad core
processor, one USB 3.0 port, and one adjacent USB 2.0 or USB 3.0 port.
Note: RF recording using streaming I/Q bandwidths > 8 MHz requires the computer’s mass storage drive to have at
least 250MB/sec of sustained write speed such as an SSD, RAID-0, or RAID-5.
