S P E C I F I C A T I O N S
Synchronization (≤ 20 MHz IBW)
1 PPS GPS input port enables ± 50ns time-stamping
Operating Temperature: 32°F to 149°F (0°C to +65°C) Standard;
-40°F to 149°F (-40°C to +65°C) for Option-1
Weight
Net, 1.10 lbs. (0.50 kg)
Size
8.63” x 3.19” x 1.19” (219mm x 81mm x 30mm)
Power: one USB 3.0 port and one adjacent USB 2.0 or USB 3.0 port
Control and Communication: USB 3.0 serial bus
*DANL, Residual Responses, Spurious Mixer Responses, and Phase Noise specifications apply only at 20°C to 25°C. Typical variations, over the
analyzer’s operating temperature, from the specifications at 20°C to 25°C are published in Appendix: Typical Performance Characteristics of
the BB60C.
